PVC Insulated Copper Wire
High-quality copper wires insulated with thermoplastic PVC (Polyvinyl Chloride), engineered for internal wiring in residential and commercial buildings. These wires offer excellent electrical reliability and long-term performance, providing superior resistance against heat, abrasion, and wear. Ideal for connection in distribution boards, domestic installations, and various electrical appliances, with multiple core and cross-section options to meet diverse application requirements.
High-quality copper wires insulated with thermoplastic PVC (Polyvinyl Chloride), engineered for internal wiring in residential and commercial buildings. These wires offer excellent electrical reliability and long-term performance, providing superior resistance against heat, abrasion, and wear. Ideal for connection in distribution boards, domestic installations, and various electrical appliances, with multiple core and cross-section options to meet diverse application requirements.
| Property |
Typical Value |
|---|---|
| Conductor |
Solid / Stranded Copper (Cu) |
| Conductor Purity |
High |
| Insulation |
Thermoplastic PVC |
| Common Cross Sections |
0.5 — 240 mm² |
| Rated Voltage |
450/750V or 0.6/1kV |
| Operating Temperature |
70°C or 90°C |
| Number of Cores |
Single, 2, 3, 4, 5 |
| Insulation Colors |
Multi-color for core identification |
| Outer Sheath/Armour |
Optional |
- Internal electrical wiring for residential and commercial buildings.
- Connection in distribution boards and electrical switches.
- Wiring various domestic and office electrical appliances.
- Compliant with relevant BS and IEC standards, e.g., BS 6004 / IEC 60227, or local SASO specifications.
- Insulation resistance testing.
- Short-circuit current testing.
- Elongation test.
- Quality assurance according to Prysmian Asean+1 standards.
